產品詳情說明
AR系列羅茨鼓風機
產品特點
●強制輸氣，流量隨壓力變小，且輸送氣體不受油污染。
●采用兩葉擺線葉型或最新氣動理論設計，高效節能。
●轉子動平衡精度高，整機振動小。
●零部件選材優良，齒輪精度高，整機可靠性高，使用壽命長。
●采用特殊消聲設計，噪聲低。
●結構簡單，造型優美，操作維護方便。
●品種規格多，性能點密集，便于選擇合適機型，有利于節能降耗。
●AR系列產品可派生AR-K、AR-M、AR-N等特殊用途羅茨鼓風機，用以輸送或抽取各種不同的氣體介質，滿足不同種類的工業用途。
流量：0.76-1200m3/min,壓力：9.8-98kPa
產品用途
● AR系列標準型羅茨鼓風機可廣泛應用于石油、化工、冶金、電力、化肥、建材、礦山、港口、輕紡、造紙、食品、醫藥、環保、空分、氣力輸送、城市燃?xì)獾刃袠I(yè)。
● AR系列標準型羅茨鼓風機，一般用于輸送干凈空氣。

AR系列羅茨鼓風機性能表  Performance Date of Series AR Roots Blowers
風機型號	口徑	轉速	各排氣壓力下的進口流量Qs(m3/min),所需軸功率La(kW)及所配電機功率Po(kW)																														電機
	bore	speed	intake  volume  Qs(m3/min)  shaft  power  required La(kW) at  each  discharge  pressure																														極數
type	mm	r/min	9.8kPa			19.6kPa			29.4kPa			39.2kPa			49.0kPa			58.8kPa			68.6kPa			78.4kPa			88.2kPa			98.0kPa			pole
		n	Qs	La	Po	Qs	La	Po	Qs	La	Po	Qs	La	Po	Qs	La	Po	Qs	La	Po	Qs	La	Po	Qs	La	Po	Qs	La	Po	Qs	La	Po	P
ARB-50	50	1450	1.49	0.67	1.1	1.28	1.00	1.5	1.12	1.32	2.2	0.99	1.65	2.2	0.87	1.98	3	0.76	2.31	3													4
		1750	1.90	0.81	1.5	1.69	1.20	2.2	1.53	1.60	2.2	1.40	1.99	3	1.28	2.39	3	1.17	2.79	4	1.07	3.18	4										4
		2000	2.24	0.92	1.5	2.03	1.37	2.2	1.88	1.83	3	1.74	2.28	3	1.62	2.73	4	1.52	3.19	4	1.42	3.64	5.5	1.33	4.09	5.5							2
		2500	2.93	1.15	1.5	2.72	1.72	3	2.56	2.28	3	2.43	2.85	4	2.31	3.42	5.5	2.20	3.98	5.5	2.10	4.55	7.5	2.01	5.11	7.5	1.93	5.68	7.5				2
		3000	3.61	1.38	2.2	3.41	2.06	3	3.25	2.74	4	3.11	3.42	5.5	2.99	4.10	5.5	2.89	4.78	7.5	2.79	5.46	7.5	2.70	6.14	7.5	2.61	6.82	11	2.53	7.49	11	2
ARB-65	65	1450	2.15	0.99	1.5	1.85	1.46	2.2	1.61	1.94	3	1.42	2.42	3	1.24	2.90	4	1.08	3.37	5.5													4
		1750	2.75	1.19	2.2	2.45	1.77	3	2.21	2.34	3	2.01	2.92	4	1.84	3.50	5.5	1.68	4.07	5.5	1.54	4.65	5.5										4
		2000	3.25	1.36	2.2	2.95	2.02	3	2.71	2.68	4	2.51	3.34	4	2.34	4.00	5.5	2.18	4.65	7.5	2.04	5.31	7.5	1.90	5.97	7.5							2
		2500	4.25	1.70	2.2	3.94	2.53	4	3.71	3.35	5.5	3.51	4.17	5.5	3.34	4.99	7.5	3.18	5.82	7.5	3.03	6.64	11	2.90	7.46	11							2
		3000	5.25	2.04	3	4.94	3.03	4	4.71	4.02	5.5	4.51	5.01	7.5	4.33	5.99	7.5	4.18	6.98	11	4.03	7.97	11	3.90	8.96	11							2
ARC-80	80	1450	4.57	1.63	2.2	4.12	2.57	4	3.77	3.50	5.5	3.48	4.44	5.5	3.22	5.37	7.5	2.99	6.31	7.5	2.77	7.24	11										4
		1750	5.74	1.97	3	5.29	3.10	4	4.94	4.23	5.5	4.65	5.36	7.5	4.39	6.48	11	4.16	7.61	11	3.94	8.74	11	3.74	9.87	15							4
		2000	6.72	2.25	3	6.26	3.54	5.5	5.92	4.83	7.5	5.62	6.12	7.5	5.36	7.41	11	5.13	8.70	11	4.92	9.99	15	4.72	11.3	15	4.53	12.6	15				2
		2500	8.67	2.82	4	8.22	4.43	5.5	7.87	6.04	7.5	7.57	7.65	11	7.32	9.26	11	7.08	10.9	15	6.87	12.5	15	6.67	14.1	18.5	6.48	15.7	18.5	6.31	17.3	22	2
		3000	10.6	3.38	5.5	10.2	5.31	7.5	9.82	7.25	11	9.53	9.18	11	9.27	11.1	15	9.04	13.0	15	8.82	15.0	18.5	8.62	16.9	22	8.43	18.8	22	8.26	20.8	30	2
ARC-100	100	1450	6.75	2.17	3	6.24	3.53	5.5	5.85	4.85	7.5	5.51	6.17	7.5	5.22	7.48	11	4.96	8.80	11	4.71	10.1	15	4.49	11.4	15							4
		1750	8.41	2.62	4	7.89	4.26	5.5	7.50	5.85	7.5	7.17	7.44	11	6.87	9.03	11	6.61	10.6	15	6.37	12.2	15	6.14	13.8	18.5	5.93	15.4	18.5				4
		2000	9.78	2.99	4	9.27	4.87	7.5	8.88	6.69	7.5	8.54	8.50	11	8.25	10.3	15	7.99	12.1	15	7.74	14.0	18.5	7.52	15.8	18.5	7.31	17.6	22				2
		2500	12.5	3.74	5.5	12.0	6.08	7.5	11.6	8.36	11	11.3	10.6	15	11.0	12.9	15	10.7	15.2	18.5	10.5	17.5	22	10.3	19.7	22	10.1	22.0	30				2
		3000	15.3	4.49	5.5	14.8	7.30	11	14.4	10.0	15	14.1	12.8	15	13.8	15.5	18.5	13.5	18.2	22	13.3	20.9	30	13.0	23.7	30							2
ARD-100*	125	970	6.33	2.19	4	5.74	3.48	5.5	5.30	4.77	7.5	4.92	6.06	7.5	4.58	7.35	11	4.28	8.64	11	4.00	9.93	15										6
		1150	7.77	2.60	4	7.18	4.13	5.5	6.73	5.66	7.5	6.35	7.19	11	6.02	8.71	11	5.72	10.2	15	5.44	11.8	15	5.18	13.3	18.5							4
		1450	10.2	3.27	5.5	9.57	5.20	7.5	9.13	7.13	11	8.75	9.06	11	8.41	11.0	15	8.11	12.9	18.5	7.84	14.8	18.5	7.58	16.8	22	7.33	18.7	22				4
		1750	12.6	3.95	5.5	12.0	6.28	7.5	11.5	8.61	11	11.1	10.9	15	10.8	13.3	18.5	10.5	15.6	18.5	10.2	17.9	22	10.0	20.2	30	9.73	22.6	30	9.50	24.9	30	4
		2000	14.5	4.52	5.5	14.0	7.18	11	13.5	9.84	15	13.1	12.5	15	12.8	15.2	18.5	12.5	17.8	22	12.2	20.5	30	12.0	23.1	30	11.7	25.8	30	11.5	28.5	37	2
		2200	16.1	4.97	7.5	15.6	7.89	11	15.1	10.8	15	14.7	13.7	18.5	14.4	16.7	22	14.1	19.6	30	13.8	22.5	30	13.6	25.4	30	13.3	28.4	37	13.1	31.3	37	2
ARD-125	125	970	9.29	2.80	4	8.53	4.66	7.5	7.95	6.51	7.5	7.46	8.37	11	7.03	10.2	15	6.64	12.1	15	6.28	13.9	18.5	5.94	15.8	18.5							6
		1150	11.4	3.33	5.5	10.6	5.52	7.5	10.0	7.72	11	9.52	9.92	15	9.09	12.1	15	8.70	14.3	18.5	8.34	16.5	22	8.00	18.7	22	7.69	20.9	30				4
		1450	14.8	4.19	5.5	14.0	6.96	11	13.5	9.74	11	13.0	12.5	15	12.5	15.3	18.5	12.1	18.1	22	11.8	20.8	30	11.4	23.6	30	11.1	26.4	30	10.8	29.1	37	4
		1750	18.2	5.06	7.5	17.5	8.41	11	16.9	11.8	15	16.4	15.1	18.5	16.0	18.4	22	15.6	21.8	30	15.2	25.1	30	14.9	28.5	37	14.6	31.8	37	14.3	35.2	45	4
		2000	21.1	5.78	7.5	20.3	9.61	11	19.8	13.4	18.5	19.3	17.3	22	18.8	21.1	30	18.5	24.9	30	18.1	28.7	37	17.8	32.5	37	17.4	36.4	45	17.1	40.2	45	2
		2200	23.4	6.36	7.5	22.6	10.6	15	22.1	14.8	18.5	21.6	19.0	22	21.1	23.2	30	20.7	27.4	37	20.4	31.6	37	20.0	35.8	45	19.7	40.0	45	19.4	44.2	55	2
ARD-127*	125	970	11.3	3.43	5.5	10.4	5.69	7.5	9.74	7.94	11	9.15	10.2	15	8.63	12.5	15	8.16	14.7	18.5	7.73	17.0	22										6
		1150	13.9	4.06	5.5	13.0	6.74	11	12.3	9.42	11	11.7	12.1	15	11.1	14.8	18.5	10.7	17.4	22	10.2	20.1	30	9.84	22.8	30							4
		1450	18.1	5.12	7.5	17.1	8.50	11	16.4	11.9	15	15.9	15.2	18.5	15.3	18.6	22	14.9	22.0	30	14.4	25.4	30	14.0	28.7	37	13.7	32.1	37				4
		1750	22.2	6.18	7.5	21.3	10.3	15	20.6	14.3	18.5	20.0	18.4	22	19.5	22.5	30	19.1	26.6	30	18.6	30.6	37	18.2	34.7	45	17.8	38.8	45				4
		2000	25.7	7.07	11	24.8	11.7	15	24.1	16.4	22	23.5	21.0	30	23.0	25.7	30	22.5	30.3	37	22.1	35.0	45	21.7	39.7	45	21.3	44.3	55				2
		2200	28.5	7.77	11	27.6	12.9	15	26.9	18.0	22	26.3	23.1	30	25.8	28.3	37	25.3	33.4	45	24.9	38.5	45	24.5	43.6	55	24.1	48.7	55				2
ARD-145	150	970	14.2	4.29	5.5	13.1	7.11	11	12.3	9.94	15	11.6	12.8	15	10.9	15.6	18.5	10.4	18.4	22	9.82	21.2	30										6
		1150	17.4	5.09	7.5	16.3	8.43	11	15.4	11.8	15	14.7	15.1	18.5	14.1	18.5	22	13.5	21.8	30	13.0	25.2	30	12.5	28.5	37							4
		1450	22.6	6.42	7.5	21.5	10.6	15	20.7	14.9	18.5	19.9	19.1	22	19.3	23.3	30	18.7	27.5	37	18.2	31.7	37	17.7	35.9	45	17.2	40.2	45				4
		1750	27.9	7.74	11	26.7	12.8	15	25.9	17.9	22	25.2	23.0	30	24.5	28.1	37	24.0	33.2	37	23.4	38.3	45	22.9	43.4	55	22.5	48.5	55				4
		2000	32.2	8.85	11	31.1	14.7	18.5	30.3	20.5	30	29.5	26.3	30	28.9	32.1	37	28.3	37.9	45	27.8	43.8	55	27.3	49.6	55	26.9	55.4	75				2
		2200	35.7	9.73	11	34.6	16.1	18.5	33.8	22.5	30	33.0	28.9	37	32.4	35.3	45	31.8	41.7	55	31.3	48.1	55	30.8	54.5	75							2
ARD-150	150	970	17.7	5.22	7.5	16.4	8.68	11	15.4	12.2	15	14.6	15.6	18.5	13.8	19.1	22	13.2	22.6	30	12.5	26.0	30										6
		1150	21.5	6.19	7.5	20.2	10.3	15	19.3	14.4	18.5	18.4	18.5	22	17.7	22.6	30	17.0	26.7	30	16.4	30.8	37										4
		1450	28.0	7.80	11	26.7	13.0	15	25.7	18.2	22	24.9	23.3	30	24.1	28.5	37	23.5	33.7	45	22.8	38.9	45	22.3	44.1	55							4
		1750	34.4	9.41	11	33.1	15.7	18.5	32.1	21.9	30	31.3	28.2	37	30.6	34.4	45	29.9	40.7	45	29.3	46.9	55	28.7	53.2	75							4
		2000	39.8	10.8	15	38.5	17.9	22	37.5	25.1	30	36.6	32.2	37	35.9	39.4	45	35.2	46.5	55	34.6	53.7	75										2
ARE-145*	150	730	17.8	5.27	7.5	16.5	8.74	11	15.6	12.2	15	14.7	15.7	18.5	14.0	19.1	22	13.4	22.6	30	12.8	26.1	30	12.2	29.5	37	11.7	33.0	45				8
		970	24.6	7.00	11	23.4	11.6	15	22.4	16.2	22	21.6	20.8	30	20.9	25.4	30	20.2	30.0	37	19.6	34.6	45	19.1	39.3	45	18.6	43.9	55	18.1	48.5	55	6
		1170	30.3	8.44	11	29.1	14.0	18.5	28.1	19.6	30	27.3	25.1	30	26.6	30.7	37	25.9	36.2	45	25.3	41.8	55	24.8	47.3	55	24.3	52.9	75	23.8	58.5	75	4
		1250	32.6	9.02	11	31.3	15.0	18.5	30.4	20.9	30	29.6	26.8	37	28.8	32.8	45	28.2	38.7	45	27.6	44.6	55	27.1	50.6	75	26.5	56.5	75	26.0	62.5	75	4
		1350	35.4	9.74	15	34.2	16.2	22	33.2	22.6	30	32.4	29.0	37	31.7	35.4	45	31.1	41.8	55	30.5	48.2	55	29.9	54.6	75	29.4	61.0	75	28.9	67.5	75	4
		1450	38.3	10.5	15	37.0	17.4	22	36.1	24.2	30	35.3	31.1	37	34.5	38.0	45	33.9	44.9	55	33.3	51.8	75	32.8	58.7	75	32.2	65.6	75	31.7	72.5	90	4
ARE-190	200	730	23.0	6.46	11	21.5	10.9	15	20.3	15.4	18.5	19.3	19.8	22	18.4	24.3	30	17.6	28.7	37	16.9	33.2	37	16.2	37.7	45	15.6	42.1	55				8
		970	31.8	8.58	11	30.3	14.5	18.5	29.1	20.4	30	28.1	26.4	30	27.2	32.3	37	26.4	38.2	45	25.7	44.1	55	25.0	50.1	55	24.4	56.0	75	23.8	61.9	75	6
		1170	39.1	10.4	15	37.6	17.5	22	36.4	24.6	30	35.4	31.8	37	34.5	38.9	45	33.7	46.1	55	33.0	53.2	75	32.3	60.4	75	31.7	67.5	75	31.1	74.7	90	4
		1250	42.1	11.1	15	40.5	18.7	22	39.4	26.3	30	38.4	34.0	45	37.5	41.6	45	36.7	49.2	55	35.9	56.9	75	35.3	64.5	75	34.6	72.1	90	34.0	79.8	90	4
		1350	45.7	11.9	15	44.2	20.2	30	43.0	28.4	37	42.0	36.7	45	41.1	44.9	55	40.3	53.2	75	39.6	61.4	75	38.9	69.7	90	38.3	77.9	90	37.7	86.1	110	4
		1450	49.4	12.8	18.5	47.9	21.7	30	46.7	30.5	37	45.7	39.4	45	44.8	48.3	55	44.0	57.1	75	43.3	66.0	75	42.6	74.8	90	42.0	83.7	110	41.4	92.5	110	4
ARE-195	200	730	29.1	7.97	11	27.2	13.5	18.5	25.8	19.1	22	24.7	24.7	30	23.6	30.3	37	22.7	35.8	45	21.8	41.4	55	21.0	47.0	55	20.3	52.6	75	19.6	58.1	75	8
		970	40.0	10.6	15	38.2	18.0	22	36.8	25.4	30	35.7	32.8	37	34.6	40.2	45	33.7	47.6	55	32.8	55.0	75	32.0	62.4	75	31.3	69.8	90	30.6	77.2	90	6
		1170	49.2	12.8	15	47.4	21.7	30	46.0	30.6	37	44.8	39.6	45	43.8	48.5	55	42.8	57.4	75	42.0	66.4	75	41.2	75.3	90	40.4	84.2	110	39.7	93.2	110	4
		1250	52.9	13.7	18.5	51.1	23.2	30	49.7	32.7	37	48.5	42.3	55	47.4	51.8	75	46.5	61.4	75	45.6	70.9	90	44.8	80.5	90	44.1	90.0	110	43.4	99.5	110	4
		1350	57.4	14.7	18.5	55.6	25.1	30	54.2	35.4	45	53.1	45.7	55	52.0	56.0	75	51.1	66.3	75	50.2	76.6	90	49.4	86.9	110	48.7	97.2	132	48.0	107	132	4
		1450	62.0	15.8	18.5	60.2	26.9	30	58.8	38.0	45	57.6	49.0	55	56.6	60.1	75	55.7	71.2	90	54.8	82.3	90	54.0	93.3	110	53.3	104	132	52.5	115	132	4
ARE-200	200	730	36.2	9.6	11	34.2	16.4	22	32.7	23.2	30	31.5	30.0	37	30.4	36.9	45	29.4	43.7	55	28.4	50.5	75	27.6	57.3	75	26.8	64.1	75				8
		970	49.6	12.8	15	47.7	21.8	30	46.2	30.9	37	44.9	39.9	45	43.8	49.0	55	42.8	58.0	75	41.9	67.1	75	41.0	76.1	90	40.2	85.2	110	39.4	94.2	110	6
		1170	60.8	15.4	18.5	58.9	26.3	30	57.4	37.2	45	56.1	48.2	55	55.0	59.1	75	54.0	70.0	90	53.1	80.9	90	52.2	91.8	110	51.4	103	132				4
		1250	65.3	16.5	18.5	63.3	28.1	37	61.8	39.8	45	60.6	51.4	75	59.5	63.1	75	58.5	74.8	90	57.5	86.4	110	56.7	98.1	110	55.9	110	132				4
		1350	70.9	17.8	22	68.9	30.4	37	67.4	43.0	55	66.2	55.6	75	65.1	68.2	75	64.1	80.8	90	63.1	93.4	110	62.3	106	132							4
		1450	76.5	19.1	22	74.5	32.6	37	73.0	46.1	55	71.8	59.7	75	70.7	73.2	90	69.7	86.7	110	68.7	100	110	67.9	114	132	67.1	127	160	66.3	141	160	4
ARE-250	250	730	46.1	11.7	15	43.7	20.3	30	41.8	29.0	37	40.2	37.7	45	38.8	46.3	55	37.6	55.0	75	36.4	63.7	75										8
		970	63.2	15.5	18.5	60.8	27.0	30	58.9	38.5	45	57.3	50.1	55	55.9	61.6	75	54.7	73.1	90	53.5	84.6	110										6
		1170	77.5	18.7	22	75.0	32.6	37	73.2	46.5	55	71.6	60.4	75	70.2	74.3	90	68.9	88.2	110	67.8	102	132										4
		1250	83.2	20.0	30	80.7	34.8	45	78.9	49.7	55	77.3	64.5	75	75.9	79.4	90	74.6	94.2	110	73.5	109	132										4
		1350	90.3	21.6	30	87.9	37.6	45	86.0	53.6	75	84.4	69.7	75	83.0	85.7	110	81.8	102	132													4
		1450	97.4	23.2	30	95.0	40.4	45	93.1	57.6	75	91.5	74.8	90	90.1	92.1	110	88.9	109	132	87.7	126	160										4
ARF-245	250	730	71.4	17.9	22	68.5	31.0	37	66.2	44.1	55	64.3	57.2	75	62.6	70.3	90	61.1	83.4	110	59.7	96.5	110	58.3	110	132	57.1	123	160	56.0	136	160	8
		800	79.0	19.6	22	76.0	34.0	45	73.7	48.3	55	71.8	62.7	75	70.1	77.1	90	68.6	91.4	110	67.2	106	132	65.9	120	132	64.7	134	160	63.5	149	185	6
		880	87.6	21.6	30	84.6	37.4	45	82.4	53.2	75	80.4	69.0	75	78.7	84.8	110	77.2	101	110	75.8	116	132	74.5	132	160	73.3	148	185	72.1	164	185	6
		980	98.4	24.0	30	95.4	41.6	55	93.1	59.2	75	91.2	76.8	90	89.5	94.4	110	88.0	112	132	86.6	130	160	85.3	147	185	84.0	165	185	82.9	182	200	6
ARF-250	250	730	89.2	21.9	30	85.6	38.2	45	82.8	54.5	75	80.5	70.8	90	78.4	87.1	110	76.6	103	132	74.9	120	132	73.3	136	160	71.8	152	185				8
		800	98.5	24.0	30	95.0	41.9	55	92.2	59.7	75	89.9	77.6	90	87.8	95.5	110	86.0	113	132	84.3	131	160	82.7	149	185	81.2	167	185	79.8	185	200	6
		880	109.3	26.4	37	105.7	46.1	55	102.9	65.7	75	100.6	85.4	110	98.5	105	132	96.7	125	160	95.0	144	160	93.4	164	185	91.9	184	200	90.5	203	220	6
		980	122.7	29.4	37	119.1	51.3	75	116.3	73.2	90	114.0	95.1	110	112.0	117	132	110.1	139	160	108.4	161	185	106.8	183	200	105.3	205	220	103.9	226	250	6
ARF-290*	300	730	105.6	25.0	30	101.5	44.2	55	98.5	63.5	75	95.8	82.7	90	93.6	102	132	91.5	121	132	89.6	140	160	87.8	160	185	86.1	179	200	84.5	198	220	8
		800	116.6	27.4	37	112.6	48.5	55	109.5	69.5	90	106.9	90.6	110	104.6	112	132	102.5	133	160	100.6	154	185	98.8	175	200	97.2	196	220	95.6	217	250	6
		880	129.3	30.2	37	125.2	53.3	75	122.2	76.5	90	119.5	100	110	117.2	123	160	115.2	146	160	113.3	169	185	111.5	192	220	109.8	215	250	108.2	239	280	6
		980	145.1	33.6	45	141.0	59.4	75	137.9	85.2	110	135.3	111	132	133.0	137	160	131.0	163	185	129.1	188	220	127.3	214	250	125.6	240	280	124.0	266	315	6
ARF-295	300	730	112.0	26.2	37	107.7	46.6	55	104.4	66.9	75	101.7	87.3	110	99.2	108	132	97.0	128	160	95.0	148	185	93.1	169	185	91.3	189	220	89.7	210	250	8
		800	123.7	28.7	37	119.4	51.0	75	116.2	73.4	90	113.4	95.7	110	110.9	118	132	108.8	140	160	106.7	163	185	104.8	185	200	103.1	207	250	101.4	230	250	6
		880	137.1	31.6	37	132.8	56.1	75	129.6	80.7	90	126.8	105	132	124.4	130	160	122.2	154	185	120.1	179	200	118.2	204	220	116.5	228	250	114.8	253	280	6
		980	153.9	35.1	45	149.6	62.5	75	146.3	89.9	110	143.5	117	132	141.1	145	160	138.9	172	185	136.9	199	220	135.0	227	250	133.2	254	280	131.6	281	315	6
ARF-300	300	730	138.7	31.3	37	133.9	56.4	75	130.3	81.4	90	127.2	106	132	124.5	132	160	122.0	157	185	119.8	182	200	117.6	207	250	115.7	232	250				8
		800	153.1	34.3	45	148.4	61.8	75	144.7	89.2	110	141.6	117	132	138.9	144	160	136.4	172	200	134.2	199	220	132.1	226	250							6
		880	169.6	37.8	45	164.8	68.0	90	161.2	98.2	110	158.1	128	160	155.4	159	185	152.9	189	220	150.6	219	250	148.5	249	280							6
		980	190.2	42.1	55	185.4	75.7	90	181.7	109	132	178.6	143	160	175.9	177	200	173.5	210	250	171.2	244	280	169.1	277	315	167.1	311	355	165.3	345		6
ARF-350*	350	730	164.8	37.2	45	159.3	66.9	75	155.1	96.6	110	151.5	126	160	148.3	156	185	145.5	186	200	142.8	215	250										8
		800	181.9	40.8	55	176.4	73.3	90	172.1	106	132	168.6	138	160	165.4	171	185	162.6	204	220													6
		880	201.4	44.8	55	195.9	80.6	90	191.7	116	132	188.1	152	185	184.9	188	220	182.1	224	250													6
		980	225.9	49.9	75	220.3	89.8	110	216.1	130	160	212.5	170	185	209.3	209	250	206.5	249	280	203.9	289	315										6
ARMG-300	300	730	128	30.2	37	123	53.4	75	120	76.6	90	117	100	110	114	123	160	112	146	160	110	169	185	108	193	220	106	216	250	104	239	280	8
		980	176	40.5	45	171	71.7	90	167	103	132	164	134	160	162	165	185	159	196	220	157	227	250	155	258	280	153	290	315	152	321	355	6
ARMG-350	350	730	160	36.4	45	154	65.3	75	150	94.2	110	146	123	160	143	152	185	140	181	200	138	210	250	135	239	280	133	268	315				8
		980	219	48.9	55	214	87.6	110	209	126	160	206	165	185	203	204	220	200	243	280	197	282	315	195	320	355	192	359	400				6
ARMG-395	400	730	184	41.1	55	177	74.3	90	173	107	132	169	141	160	165	174	200	162	207	250	159	240	280	156	273	315							8
		980	252	55.2	75	246	99.7	110	241	144	160	237	189	220	233	233	250	230	278	315	227	322	355	224	367	400							6
ARMG-400	400	730	204	45.3	55	198	82.1	90	193	119	132	188	156	185	184	193	220	181	229	250	178	266	280										8
		980	280	60.8	75	273	110	132	268	160	185	264	209	250	260	258	280	256	308	355	253	357	400										6
ARG-350*	350	590	185	43.9	55	180	76.8	90	176	110	132	173	143	160	170	175	200	167	208	250	165	241	280	163	274	315	161	307	355				10
		740	235	55.1	75	230	96.3	110	226	138	160	223	179	200	220	220	250	217	261	280	215	303	355	213	344	400	211	385	450	208.7	426	450	8
ARG-400	400	590	232	53.3	75	226	94.7	110	221	136	160	217	177	200	213	219	250	210	260	280	207	301	315	204	343	400	201	384	450				10
		740	295	66.9	75	289	119	132	284	171	185	280	222	250	276	274	315	273	326	355	270	378	400	267	430	500	264	482	560				8
ARG-445	450	590	262	59.5	75	255	106	132	250	153	185	246	199	220	242	246	280	238	292	315	235	339	355	232	385	450							10
		740	333	74.6	90	326	133	160	321	191	220	317	250	280	313	308	355	309	366	400	306	425	450	303	483	560							8
ARG-450	450	590	293	65.2	75	285	117	132	280	169	185	275	220	250	271	272	315	267	324	355	264	375	400	261	427	450							10
		740	371	81.8	90	364	147	160	359	211	250	354	276	315	350	341	400	346	406	450	343	471	500	339	536	560							8
ARG-500	500	590	362	78.9	90	353	143	160	346	207	220	341	271	315	336	322	355	331	398	450	327	462	500										10
		740	459	99.0	110	451	179	200	444	259	280	438	339	355	433	420	450	428	500	560	424	580	630										8
ARMH-550	600	490	406	95	110	395	166	200	387	238	280	380	310	355	374	382	450	368	453	500	363	525	560	358	597	630	354	669	800				12
		590	495	114	132	484	200	220	475	287	315	468	373	400	462	460	500	456	546	630	451	632	710	446	719	800	442	805	900				10
ARMH-600	600	490	428	99	110	417	174	200	408	250	280	400	325	355	394	401	450	388	476	560	383	552	630	378	627	710	373	703	800				12
		590	521	119	132	509	210	250	501	301	355	493	391	450	487	482	560	481	573	630	476	664	710	471	755	800	466	846	900				10
ARMH-650	600	490	467	106	132	456	189	220	446	271	315	438	354	400	432	436	500	425	519	560	419	601	710	414	684	800							12
		590	569	128	160	557	227	250	548	327	355	540	426	500	533	525	560	527	625	710	521	724	800	516	823	900							10
ARMH-700	700	490	536	121	160	522	216	250	511	310	355	502	405	450	494	499	560	487	593	630	480	688	800										12
		590	652	146	185	638	260	280	627	374	400	618	487	560	610	601	710	603	715	800	596	828	900										10
ARMH-750	700	490	608	136	185	592	243	280	581	350	400	571	457	500	562	564	630	554	671	710													12
		590	740	164	200	724	293	315	712	421	450	702	550	630	693	679	710	686	808	900													10
ARH-600	600	490	559	127	160	545	225	250	533	324	355	524	423	450	515	522	560	507	620	710	500	719	800	494	818	900	488	917	1000				12
		590	681	153	185	666	271	315	655	390	450	645	509	560	637	628	710	629	747	800	622	866	1000	615	985	1120	609	1104	1250				10
ARH-700	700	490	744	162	185	724	293	315	709	424	450	697	555	630	686	686	800	676	817	900	667	948	1000										12
		590	905	195	220	886	353	400	871	511	560	858	669	710	847	826	900	837	984	1120	828	1142	1250										10
ARH-800	800	490	869	187	220	847	340	400	831	493	560	817	646	710	804	799	900																12
		590	1057	225	250	1036	409	450	1019	593	630	1005	777	900	992	961	1120																10
ARH-900	900	490	1034	219	250	1009	400	450	991	582	630	975	763	900	961	944	1000																12
		590	1257	264	315	1232	482	560	1214	700	800	1198	919	1000	1184	1137	1250																10
